Dell EMC PowerEdge T560 8×3.5″ Server

The Dell EMC PowerEdge T560 8×3.5″ Server is a purpose-built enterprise-class tower server designed for organizations that need to balance performance, scalability, and security within a compact, office-friendly footprint. Equipped with the latest 4th and 5th Gen Intel® Xeon® Scalable processors, advanced DDR5 memory, PCIe Gen5 expansion, and flexible GPU acceleration, this system delivers next-generation performance for mission-critical workloads. Unlike smaller office servers, the Dell EMC PowerEdge T560 8×3.5″ Server is built to handle traditional IT environments, virtualization, database management, analytics, and even AI/ML inferencing—all while maintaining quiet acoustics suitable for office or branch deployment.

From its cyber-resilient architecture to its expandable drive bays supporting both HDDs and NVMe SSDs, the T560 is engineered to grow with your business. IT managers will appreciate the automation and centralized management features of Dell OpenManage™, while sustainability-driven organizations will value Dell’s focus on recyclable materials and energy-efficient designs. Whether you’re looking to modernize your infrastructure, support advanced workloads, or future-proof your IT operations, the Dell EMC PowerEdge T560 8×3.5″ Server is built to meet enterprise-level standards.

Key Advantages of the Dell EMC PowerEdge T560 8×3.5″ Server

• Scalability for Growth: Supports up to two Intel Xeon Scalable processors, 16 DDR5 DIMM slots (up to 1.5TB), and PCIe Gen5 slots for unmatched performance and headroom.

• Flexible Storage Options: Configurable with up to 8 x 3.5″ SAS/SATA drives in the front bays, with expansion to hybrid configurations including 2.5″ NVMe SSDs for high-performance storage tiers.

• GPU Acceleration: Ideal for AI, ML, and VDI workloads, supporting up to 2 x 300W double-wide GPUs or 6 x 75W single-wide GPUs.

• Enterprise-Level Security: Equipped with silicon-based Root of Trust, cryptographically signed firmware, Secure Boot, and TPM 2.0 for compliance with Zero Trust IT strategies.

• Efficient Management: Integrated with iDRAC9, OpenManage Enterprise, and API integrations for centralized and automated server fleet management.

• Office-Friendly Design: Despite being an enterprise powerhouse, it operates with quiet acoustics, making it suitable for deployment in office and branch environments.

• Sustainable IT: Built with recycled materials, energy-efficient power supplies, and Dell Technologies’ end-of-life recycling services.

Detailed Specifications of the Dell EMC PowerEdge T560 8×3.5″ Server

The true strength of the Dell EMC PowerEdge T560 8×3.5″ Server lies in its versatile, highly configurable hardware. Below is a breakdown of its main technical specifications:

Processor Options

• Up to two 4th Gen Intel Xeon Scalable processors with up to 32 cores per processor.

• Up to two 5th Gen Intel Xeon Scalable processors with up to 28 cores per processor.

• Enhanced support for advanced workloads such as virtualization, analytics, AI/ML inferencing, and traditional enterprise IT applications.

Memory

• 16 DDR5 DIMM slots supporting RDIMM up to 1.5TB maximum.

• Memory speeds up to 4800 MT/s (4th Gen Xeon) and 5200 MT/s (5th Gen Xeon).

• ECC DDR5 registered DIMMs only, ensuring data integrity and reliability for mission-critical operations.

Storage

• Flexible front drive bay options supporting HDD, SAS SSD, SATA SSD, and NVMe SSD:

  • Up to 8 x 3.5″ SAS/SATA HDD drives (up to 120TB capacity).

  • Hybrid option: 8 x 3.5″ SAS/SATA HDD + 8 x 2.5″ NVMe SSD drives (up to 240TB).

  • Expansion to up to 24 x 2.5″ SAS/SATA drives (up to 360TB).

• Internal boot options:

  • BOSS-N1 supporting 2 x M.2 NVMe SSD drives or USB.

• Storage controllers:

  • fPERC H965i, H755N, H755, H355, HBA355i, HBA465i.

  • Software RAID: S160 for NVMe drives.

Expansion Slots & GPU

• Up to six PCIe slots for maximum expandability.

  • 2 x PCIe Gen5 full height, full length.

  • Multiple PCIe Gen4 slots for legacy compatibility.

• GPU support:

  • Up to 2 x 300W double-wide GPUs or 6 x 75W single-wide GPUs.

• Ideal for GPU-accelerated workloads like AI training, inference, and data visualization.

Power & Cooling

• Multiple hot-swappable power supply units:

  • 600W, 700W, 800W, 1100W, 1400W, 1800W, 2400W, and up to 2800W Titanium PSUs.

• High-performance air cooling with up to 8 fans, supporting standard and high-performance configurations.

Networking

• 2 x 1GbE embedded NIC (LOM) standard.

• Expandable with 1 x OCP 3.0 card slot for advanced connectivity.

• Supports simultaneous LOM and OCP usage.

Ports

• Front ports: 1 x USB 2.0, 1 x USB 3.0, 1 x iDRAC Direct (Micro-AB USB).

• Rear ports: 1 x USB 2.0, 1 x USB 3.0, 1 x Serial (optional), 1 x dedicated iDRAC RJ45, 1 x VGA, 2 x Ethernet.

• Internal ports: 1 x USB 3.0 (optional).

Security Features

• Silicon Root of Trust ensuring hardware integrity.

• Secure Boot and Secure Erase.

• Data at Rest Encryption with local/external key management.

• System Lockdown with iDRAC9 Enterprise/Datacenter license.

• TPM 2.0 (FIPS, CC-TCG certified, China NationZ supported).

Management & Automation

• Embedded iDRAC9 for remote server management.

• Integration with OpenManage Enterprise, Microsoft System Center, VMware vCenter, ServiceNow, Ansible, and Terraform.

• CloudIQ integration for predictive analytics.

• OpenManage Mobile for IT teams on the go.

Operating Systems & Hypervisors

• Compatible with:

  • Canonical Ubuntu Server LTS

  • Microsoft Windows Server with Hyper-V

  • Red Hat Enterprise Linux (RHEL)

  • SUSE Linux Enterprise Server

  • VMware ESXi

Form Factor & Dimensions

• Tower form factor (4.5U).

• Height: 464mm (with feet), 508mm (with wheels), 446mm (without feet).

• Width: 200mm.

• Depth: 678mm (with bezel), 660mm (without bezel).

• Office-friendly design with quiet acoustics.

Why Choose the Dell EMC PowerEdge T560 8×3.5″ Server?

The Dell EMC PowerEdge T560 8×3.5″ Server isn’t just about raw specifications—it’s about real-world value for businesses:

• Versatility: Supports diverse workloads, from traditional IT and databases to virtualization and AI.

• Future-Proofing: PCIe Gen5, DDR5, and GPU readiness ensure long-term performance scalability.

• Reliability: Enterprise-grade hardware with ECC memory, secure boot, and advanced RAID controllers.

• Simplified IT Operations: Centralized management and automation reduce complexity for IT administrators.

• Sustainability & Cost Savings: Energy-efficient power supplies and sustainable materials lower operational costs.

• Global Support: Dell ProSupport, ProDeploy, and consulting services available in over 170 countries.

Use Cases of the Dell EMC PowerEdge T560 8×3.5″ Server

• Corporate IT Infrastructure: Central file, application, and domain server.

• Database & Analytics: High-capacity storage and compute for structured and unstructured data.

• Virtualization: Consolidate multiple virtual machines with strong CPU and memory support.

• AI/ML Inferencing: Accelerated performance with GPU support for AI workloads.

• Branch & Remote Offices: Office-friendly acoustics and compact form factor ideal for non-datacenter environments.

Conclusion

The Dell EMC PowerEdge T560 8×3.5″ Server is more than a tower—it’s an enterprise platform ready to handle next-generation business challenges. With its powerful Xeon processors, DDR5 memory, PCIe Gen5 expansion, scalable storage, and GPU readiness, it can manage everything from virtualization and databases to AI workloads. Its cyber-resilient architecture ensures data protection, while Dell’s OpenManage portfolio makes IT operations seamless and automated.

For organizations seeking a balance of performance, scalability, and sustainability, the Dell EMC PowerEdge T560 8×3.5″ Server is a future-ready choice. It provides enterprise-grade reliability in a tower design that is office-friendly, secure, and built for mission-critical workloads.

Check full specs and datasheet below: Spec sheet, Technical Guide
