Cisco Nexus 5548UP 32 port is a high-performance, low-latency data center switch designed for scalable, unified fabric deployments. It supports flexible Unified Ports, enabling both Ethernet and Fibre Channel, making it ideal for enterprise and cloud environments.
Specifications:
Ports: 32 fixed Unified Ports (Ethernet/FCoE/FC), expandable to 48 with expansion module
Power Supply: Dual redundant, hot-swappable AC
Layer: Layer 2 / Layer 3
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
Pick up from the Woodmart Store
To pick up today
Free
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
Warranty 1 year
Free 30-Day returns
Payment Methods:
The Cisco Nexus 5548UP 32 is a high-performance, rack-mountable, unified-port switch in the Nexus 5000 series, designed to serve modern data centers and enterprise server-access layers. This 1RU switch delivers up to 960 Gbps of throughput and combines 32 configurable unified SFP+ ports with optional expansion—offering seamless support for Ethernet, Fibre Channel-over-Ethernet (FCoE), and native Fibre Channel protocols. Built to adapt, the Cisco Nexus 5548UP provides connectivity versatility, low-latency cut-through switching, and modular expansion capabilities, making it an ideal choice for converged LAN/SAN environments.
The Cisco Nexus 5548UP 32 blends enterprise-class performance with deployment flexibility, serving as a backbone for unified data center fabrics while remaining simple to scale.
Key benefits include:
Unified Connectivity – 32 unified ports that can be flexibly assigned as Ethernet, FCoE, or native Fibre Channel, offering unmatched adaptability in converged network stacks.
Modular Expansion Slot – Supports optional GEM modules, such as 16-port Ethernet/FCoE, combined FC plus Ethernet, or high-density QSFP modules, allowing custom scalability.
High Performance & Low Latency – Offers line-rate forwarding with 960 Gbps of switching capacity and low, consistent latency via cut-through architecture.
Redundant and Efficient Design – Equipped with dual 750W hot-swappable power supplies and front-to-back or back-to-front configurable airflow, designed for data center efficiency.
This powerful combination makes the Cisco Nexus 5548UP 32 a versatile, high-performing switch fit for demanding data center, virtualization, and storage convergence deployments.
The Cisco Nexus 5548UP 32 features 32 fixed SFP+ unified ports that can be provisioned for 1/10 GbE, FCoE, or 8/4/2/1 Gbps native Fibre Channel, enabling true network convergence.
Its single expansion slot can accommodate various Generic Expansion Modules (GEMs):
16-port Ethernet/FCoE module
8-port Ethernet/FCoE plus 8-port native Fibre Channel module
16-port unified port module
4-port QSFP 40 GbE module (each QSFP can operate in 4×10 GbE mode)
With hardware-accelerated switching and 960 Gbps capacity, the Cisco Nexus 5548UP 32 delivers predictable, wire-speed, low-latency forwarding ideal for latency-sensitive workloads.
Designed for full redundancy and serviceability:
Dual 750W AC power supplies (hot-swappable)
Two front-access fan modules
Configurable front-to-back or back-to-front airflow for hot/cold aisle alignment
Compact 1RU design (1.72 in × 17.3 in × 29.5 in; approx. 14.5 kg) enables efficient rack density.
Perfect for LAN and SAN consolidation, the unified ports and FCoE support simplify infrastructure, cabling, and administration in virtualized environments.
Ideal for rack-mount and top-of-rack aggregation, providing high-bandwidth connectivity with integrated Fibre Channel support for storage integration.
Built for HPC clusters, virtualization hosts, and trading systems requiring consistent low latency and high throughput.
Easily expandable through GEM modules and airflow-adjustable design, enabling seamless evolution of network infrastructures.
High-density throughput – 960 Gbps switching, line-rate on all interfaces.
Transparent latency – Cut-through architecture ensures stable low latency, regardless of packet type or size.
Flexible protocol support – Unified ports streamline deployment of Ethernet, FCoE, and Fibre Channel across the same hardware.
Redundant system components – Hot-swappable power and fan modules reduce downtime and improve maintainability.
Compared to fixed-port 10 GbE switches, Cisco Nexus 5548UP 32 stands out with:
Converged networking support not commonly available in many 10 GbE switching options.
Modular expansion flexibility, enabling growth and customization over time.
Efficiency and redundancy, offering hot-swappable hardware in a compact chassis.
Opting for the Cisco Nexus 5548UP 32 means gaining:
Unified protocol capability to support Ethernet, FCoE, and Fibre Channel seamlessly.
Scalable architecture that allows future growth via expansion modules.
Superior performance with low-latency wire-speed switching.
Robust data center features such as configurable airflow, redundant power, and unified management.
The Cisco Nexus 5548UP is a powerful, converged switch purpose-built for modern data centers and enterprise environments. With unified ports offering Ethernet, FCoE, or Fibre Channel support in a compact, expandable 1RU form factor, this switch delivers outstanding performance, flexibility, and reliability. Backed by Cisco’s rich data center portfolio and resilient hardware design, the Nexus 5548UP is a future-proof solution for organizations looking to streamline networking fabrics and evolve their infrastructure seamlessly.
Explore full product specifications in the datasheet provided below :
| Model Number |
Cisco Nexus 5548UP 32Port |
|---|---|
| Number of Ports |
32 fixed Unified Ports (Ethernet/FCoE/FC) |
| Port Type |
Unified ports (configurable as Ethernet, FCoE, or Fibre Channel) |
| Port Speed |
1/10 GbE or up to 8/4/2/1 Gb Fibre Channel (configurable) |
| Switching Capacity |
Up to 960 Gbps in Layer 2 |
| Forwarding Rate |
~714 Mpps (Layer 2); Layer 3 with daughter card: 160 Gbps or 240 Mpps |
| Layer Type |
Layer 2 by default; Layer 3 via optional daughter card |
| Management Type |
Fully manageable (CLI, NX-OS, SNMP, etc.) |
| Operating Temperature |
0 °C to 40 °C (typical DC ambient) |
| Power Supply |
Dual 750 W AC redundant hot-swappable PSUs |
| Dimensions (H x W x D) |
1.72 x 17.3 x 29.5 in. |
| Weight |
~35 lb (15.88 kg) with full configuration |
The Cisco Nexus 5548UP 32 is a high-performance, rack-mountable, unified-port switch in the Nexus 5000 series, designed to serve modern data centers and enterprise server-access layers. This 1RU switch delivers up to 960 Gbps of throughput and combines 32 configurable unified SFP+ ports with optional expansion—offering seamless support for Ethernet, Fibre Channel-over-Ethernet (FCoE), and native Fibre Channel protocols. Built to adapt, the Cisco Nexus 5548UP provides connectivity versatility, low-latency cut-through switching, and modular expansion capabilities, making it an ideal choice for converged LAN/SAN environments.
The Cisco Nexus 5548UP 32 blends enterprise-class performance with deployment flexibility, serving as a backbone for unified data center fabrics while remaining simple to scale.
Key benefits include:
Unified Connectivity – 32 unified ports that can be flexibly assigned as Ethernet, FCoE, or native Fibre Channel, offering unmatched adaptability in converged network stacks.
Modular Expansion Slot – Supports optional GEM modules, such as 16-port Ethernet/FCoE, combined FC plus Ethernet, or high-density QSFP modules, allowing custom scalability.
High Performance & Low Latency – Offers line-rate forwarding with 960 Gbps of switching capacity and low, consistent latency via cut-through architecture.
Redundant and Efficient Design – Equipped with dual 750W hot-swappable power supplies and front-to-back or back-to-front configurable airflow, designed for data center efficiency.
This powerful combination makes the Cisco Nexus 5548UP 32 a versatile, high-performing switch fit for demanding data center, virtualization, and storage convergence deployments.
The Cisco Nexus 5548UP 32 features 32 fixed SFP+ unified ports that can be provisioned for 1/10 GbE, FCoE, or 8/4/2/1 Gbps native Fibre Channel, enabling true network convergence.
Its single expansion slot can accommodate various Generic Expansion Modules (GEMs):
16-port Ethernet/FCoE module
8-port Ethernet/FCoE plus 8-port native Fibre Channel module
16-port unified port module
4-port QSFP 40 GbE module (each QSFP can operate in 4×10 GbE mode)
With hardware-accelerated switching and 960 Gbps capacity, the Cisco Nexus 5548UP 32 delivers predictable, wire-speed, low-latency forwarding ideal for latency-sensitive workloads.
Designed for full redundancy and serviceability:
Dual 750W AC power supplies (hot-swappable)
Two front-access fan modules
Configurable front-to-back or back-to-front airflow for hot/cold aisle alignment
Compact 1RU design (1.72 in × 17.3 in × 29.5 in; approx. 14.5 kg) enables efficient rack density.
Perfect for LAN and SAN consolidation, the unified ports and FCoE support simplify infrastructure, cabling, and administration in virtualized environments.
Ideal for rack-mount and top-of-rack aggregation, providing high-bandwidth connectivity with integrated Fibre Channel support for storage integration.
Built for HPC clusters, virtualization hosts, and trading systems requiring consistent low latency and high throughput.
Easily expandable through GEM modules and airflow-adjustable design, enabling seamless evolution of network infrastructures.
High-density throughput – 960 Gbps switching, line-rate on all interfaces.
Transparent latency – Cut-through architecture ensures stable low latency, regardless of packet type or size.
Flexible protocol support – Unified ports streamline deployment of Ethernet, FCoE, and Fibre Channel across the same hardware.
Redundant system components – Hot-swappable power and fan modules reduce downtime and improve maintainability.
Compared to fixed-port 10 GbE switches, Cisco Nexus 5548UP 32 stands out with:
Converged networking support not commonly available in many 10 GbE switching options.
Modular expansion flexibility, enabling growth and customization over time.
Efficiency and redundancy, offering hot-swappable hardware in a compact chassis.
Opting for the Cisco Nexus 5548UP 32 means gaining:
Unified protocol capability to support Ethernet, FCoE, and Fibre Channel seamlessly.
Scalable architecture that allows future growth via expansion modules.
Superior performance with low-latency wire-speed switching.
Robust data center features such as configurable airflow, redundant power, and unified management.
The Cisco Nexus 5548UP is a powerful, converged switch purpose-built for modern data centers and enterprise environments. With unified ports offering Ethernet, FCoE, or Fibre Channel support in a compact, expandable 1RU form factor, this switch delivers outstanding performance, flexibility, and reliability. Backed by Cisco’s rich data center portfolio and resilient hardware design, the Nexus 5548UP is a future-proof solution for organizations looking to streamline networking fabrics and evolve their infrastructure seamlessly.
Explore full product specifications in the datasheet provided below :
| Model Number |
Cisco Nexus 5548UP 32Port |
|---|---|
| Number of Ports |
32 fixed Unified Ports (Ethernet/FCoE/FC) |
| Port Type |
Unified ports (configurable as Ethernet, FCoE, or Fibre Channel) |
| Port Speed |
1/10 GbE or up to 8/4/2/1 Gb Fibre Channel (configurable) |
| Switching Capacity |
Up to 960 Gbps in Layer 2 |
| Forwarding Rate |
~714 Mpps (Layer 2); Layer 3 with daughter card: 160 Gbps or 240 Mpps |
| Layer Type |
Layer 2 by default; Layer 3 via optional daughter card |
| Management Type |
Fully manageable (CLI, NX-OS, SNMP, etc.) |
| Operating Temperature |
0 °C to 40 °C (typical DC ambient) |
| Power Supply |
Dual 750 W AC redundant hot-swappable PSUs |
| Dimensions (H x W x D) |
1.72 x 17.3 x 29.5 in. |
| Weight |
~35 lb (15.88 kg) with full configuration |
